U300– Standard Analog Servo with Accessory Pack
Being standard size and lightweight, it fits many applications.
6mm/25T Spline
Three pole motor
Plastic gears

SPEED:
0.23 sec/60°at 4.8V
0.19 sec/60° at 6.0V

TORQUE:
44.4 oz/in at 4.8V
57 oz/in at 6.0V

SIZE:
1.6 in x 0.8 in x 1.4 in

WEIGHT:
1.26 oz

SPEED:
0.14 sec/60°at 6.6V
0.13 sec/60° at 7.4V

TORQUE:
98.6 oz/in at 6.6V
109.7 oz/in at 7.4V

SIZE:
1.59 in x 0.79 in x 1.50 in

WEIGHT:
1.38oz

Plastic Gearing

3 Pole Cored Motor

Cast metal rudder arm with set screw drilled and tapped. Set screw is included.

Takes 1/8" rudder shaft
Over length: 1-3/16" (30mm)
Diameter (at the shaft insert): 1/2" (12mm)
Control rod hole diameter: 1/16" (1.5mm)

Cast metal rudder arm with set screw drilled and tapped. Set screw is included.

Takes 1/8" rudder shaft
Over length (from shaft insert to control rod end): 1-3/16" (30mm)
Width (looking at it as a "V"): 1-7/16" (37mm)
Diameter (at the shaft insert): 1/2" (12mm)
Control rod hole diameter: 1/16" (1.5mm)

Cast metal rudder arm with set screw drilled and tapped. Set screw is included.

Takes 3/16" rudder shaft
Over length (from shaft insert to control rod end): 1-3/16" (30mm)
Width (looking at it as a "V"): 1-7/16" (37mm)
Diameter (at the shaft insert): 1/2" (12mm)
Control rod hole diameter: 1/16" (1.5mm)

Cast metal rudder arm with set screw drilled and tapped. Set screw is included.

Takes 3/16" rudder shaft
Over length: 1-3/16" (30mm)
Diameter (at the shaft insert): 1/2" (12mm)
Control rod hole diameter: 1/16" (1.5mm)

Each quantity provides the following:
1x 4-40 Threaded Control Rod, 12" length
1x 4-40 Threaded Clevis
1x 4-40 Solder Clevis

Thread: 4-40
12" long
1/Pack

Serves for the proportional pivoting of cranes, fire monitors, guns, etc. The gear ratio (3:1) increases the swing range of a normal servo from 90° to 270°. The large disc with a diameter of 60mm is fixed on the servo, the small disc on the object to be rotated. Very simple installation.
